3 way stainless steel ball valve 1370L/PE
Reliable rack and pinion pneumatic actuator (PE series). Features spring return, adjustable travel stops, and ISO 5211 mounting. Designed for durability with a minimum of 500,000 cycles. Ideal for industrial valve automation.
Details
Three way ball valve with floating ball, reduced bore
Body in stainless steel ASTM A351 Gr. CF8M
Ball in stainless steel AISI 316
L-port
Seats in PTFE + 15% glass fiber
Max. working pressure: 69 bar (1/2'' to 11/4''), 55 bar (11/2'' to 2'')
Connection: BSP threaded
ISO mounting flange
With pneumatic actuator spring return type PE, spring to close, air to open
Details
In categories : Pneumatic actuated 3 way ball valves
