Brass throttle valve
Brass throttle valve for precise flow control in various industrial applications. Ideal for regulating fluid flow with accuracy and efficiency.
Details
Full bore - RF - 150#
Body and bonnet in A105
Disc, ball and plug in F6A
Stem in F6A
Seat in F6A
Seat inserts in Devlon
Seal in Viton
Packing in graphite
Gasket in 316+graphite
Bolts and nuts in B7M/2HM
With E-actuator with integrated controls and mechanical transmission type SA 07.6-B90/AM 01.1/GS 125.3 (208:1) DC1 RR
Actuator: SA 07.6-B90/AM 01.1
Time/outp. speed: ± 35 sec. / 90°
Duty class: S2-15 min, klasse A & B (EN 15714-2)
Power supply: 3ph/400V/50Hz
Wiring diagram: MSP1110KC3--F18E1 TPA00R1AB-101-000
Seating: Open=Limit, Close=Limit
Self-retaining: Local=Yes, Remote=Yes
IP-class: IP68 volgens EN 60529
Corrosion syst.: KS
Colour: AUMA Silver grey (similar to RAL 7037)
Torque setting: 31 Nm open, 31 Nm close
Gearbox: GS 125.3 (208:1) DC1 RR
IP-class: IP68 volgens EN 60529
Corrosion syst.: KS
Colour: AUMA Silver grey (similar to RAL 7037)
Output drive: A-stem nut, undrilled dmax. = 75 mm
Coupling bush: coupling bush with bore and keyway according to DIN6885,1 d= 55 mm
Output flange: F25-N according to ISO 5211
Max. torque: 4362 Nm
Pos. indication: Mechanical
Details
In categories : Namur solenoid pilot valves
