Carbon steel A350LF2 gate valve 119 TRIM 12 800 lbs SW

The 119 series gate valve, in forged steel A350LF2, welding SW, full bore, 1/2 stellite TRIM12 for oil, steam and high pressure industries.
Choose your configuration
See all configurations
Réf.
CONF119015
(Indicative price) €210.00
Details
Details
DN inches NPS 1/2''
Option certificate 3.1 Yes
Bonnet material Carbon steel ASTM A350 LF2
Construction standard ISO 15761 - API 602 V8
CE risk category III Module H
TRIM TRIM 12
Brand OMB
Tightness test standard API 598
Bonnet Bolted
Steam Yes
Opening device Handwheel
Application Industry
ATEX atmosphere Group II Cat. 2G/2D
Shaft/stem matérial Stainless steel ASTM A479 type 316L
ATEX compatible Yes
Diameter of passage 14.00
Face to Face (mm) 90.0
Sealing Metal / Metal
Fluid Oxygen / Argon / Nitrogen
Kv (m³/h) 10.0
Body material Carbon steel ASTM A350 LF2
Gate material Stainless steel ASTM A182 316/316L
Bore Standard
Packing gland Yes
PS (bar) 136
Connections Welding SW
Seats Stainless steel ASTM A479 316 + Stellite Gr
TS max (°C) 425
TS min (°C) -46
ATEX zone 1 & 21. 2 & 22
Warranty period 2 years
Type of stem Rising
CE Yes
Main product colour Black
Handle material Carbon steel

Configurations

Product Reference Price Stock
Produit
Carbon steel A350LF2 gate valve 119 TRIM 12 800 lbs SW 1/2''
Produit
Carbon steel A350LF2 gate valve 119 TRIM 12 800 lbs SW 3/4''
Produit
Carbon steel A350LF2 gate valve 119 TRIM 12 800 lbs SW 1''
Produit
Carbon steel A350LF2 gate valve 119 TRIM 12 800 lbs SW 1''1/2
Produit
Carbon steel A350LF2 gate valve 119 TRIM 12 800 lbs SW 2''

5 Item(s)
