Cast iron ball check valve 335 BSP
Syveco offers the check valve with ball, series 335, in cast iron GJL-250 in conformity with the standard for lifting stations NF en 12050-4, full bore avoiding head losses, inspection hatch, F/F BSP fitting
Documentation
Certificate of Conformity
pdf - 209.4 ko
Fiche technique clapet à boule NF fonte GS femelle BSP
pdf - 759.3 ko
Details
Option certificate 3.1 | Yes |
---|---|
Mounting direction | Horizontal or vertical upward flow |
Thread standard | ISO 228-1 |
Tightness test standard | ISO 5208. Rate A |
Closure member material | NBR coated aluminium |
Lifting station standard | Yes |
Application | Water supply and distribution network |
Torque (Nm) | 106.4 |
DN | 25 |
Face to Face (mm) | 141.0 |
Fluid | Cold water |
Gasket | NBR |
Kv (m³/h) | 21.0 |
Body material | Cast iron |
PS (bar) | 10 |
Connections | BSP FF |
Seats | Cast iron |
TS max (°C) | 70 |
TS min (°C) | -10 |
Warranty period | 2 years |
Obturator type | Ball |
Configurations
Product | Reference | Price | Stock | |
---|---|---|---|---|
Cast iron ball check valve 335 BSP 1'' | 335006 | €131.88 |
30 pcs available in stock
|
|
Cast iron ball check valve 335 BSP 1''1/4 | 335007 | €128.72 |
98 pcs available in stock
|
|
Cast iron ball check valve 335 BSP 1''1/2 | 335008 | €146.28 |
126 pcs available in stock
|
|
Cast iron ball check valve 335 BSP 2'' | 335009 | €157.98 |
480 pcs available in stock
|
|
Cast iron ball check valve 335 BSP 2''1/2 | 335010 | €245.75 |
60 pcs available in stock
|
|
Cast iron ball check valve 335 BSP 3'' | 335011 | €520.75 |
4 pcs available in stock
|
