Documentation
Certificate of Conformity
pdf - 195.4 ko
Notice montage robinet vanne à opercule forgée
pdf - 2.7 mo
Installation operating manual forged valve
pdf - 2.7 mo
Details
DN inches NPS | 1/2'' |
---|---|
Option certificate 3.1 | Yes |
Bonnet material | Stainless steel ASTM A182 F316 |
Construction standard | ISO 15761 - API 602 V8 |
CE risk category | III Module H |
TRIM | TRIM 10 |
Brand | OMB |
Tightness test standard | API 598 |
Bonnet | Bolted |
Steam | Yes |
Application | Industry |
ATEX atmosphere | Group II Cat. 2G/2D |
ATEX compatible | Yes |
Face to Face (mm) | 80.0 |
Sealing | Metal / Metal |
Fluid | Hydrocarbons. gas |
Kv (m³/h) | 0.9 |
Body material | Stainless steel F316/F316L |
Bore | Standard |
PS (bar) | 132 |
Connections | Welding SW |
Seats | Stainless steel ASTM A479 type 316 |
TS max (°C) | 538 |
TS min (°C) | -49 |
ATEX zone | 1 & 21. 2 & 22 |
Warranty period | 2 years |
CE | Yes |
Plug material | Stainless steel ASTM A470 AISI 316 |
Stainless steel F316 ball check valve 358 TRIM 10 800 lbs SW
The check valve series 358, TRIM 10 in forged stainless steel with ball with welding SW spring, standard bore, bolted bonnet, class 800 for oil, steam and high pressure industries.
