Stainless steel F316 ball check valve 359 TRIM 10 800 lbs NPT
The TRIM 10 check valve series 359 in forged stainless steel with NPT threaded spring, standard bore, bolted bonnet, class 800 for the oil, steam and high pressure industries.
![main product photo](https://www.syveco.com/media/catalog/product/cache/582ed6748c10bbb99b236b27a124fb97/3/5/359-clapet-bille-inox-800lbs-trim10-ff-npt.jpg)
Documentation
Details
Option certificate 3.1 | Yes |
---|---|
Bonnet material | Stainless steel ASTM A182 F316 |
Construction standard | ISO 15761 - API 602 V8 |
CE risk category | III Module H |
TRIM | TRIM 10 |
Brand | OMB |
Tightness test standard | API 598 |
Bonnet | Bolted |
Steam | Yes |
Application | Industry |
ATEX atmosphere | Group II Cat. 2G/2D |
ATEX compatible | Yes |
DN | 15 |
Face to Face (mm) | 80.0 |
Sealing | Metal / Metal |
Fluid | Oxygen / Argon / Nitrogen |
Kv (m³/h) | 0.9 |
Body material | Stainless steel F316/F316L |
Bore | Standard |
PS (bar) | 132 |
Connections | NPT FF |
Seats | Stainless steel ASTM A479 type 316 |
TS max (°C) | 538 |
TS min (°C) | -49 |
ATEX zone | 1 & 21. 2 & 22 |
Warranty period | 2 years |
CE | Yes |
Plug material | Stainless steel ASTM A470 AISI 316 |
