Mini brass ball valve 692 male/female compressed air

Find the micro ball valve brass male-male BSP with 5.5mm passage for the sectioning of water supply and distribution networks. Tightness is ensured by 1 FKM O-ring and the shaft is anti-blowout stem.
Choose your configuration
See all configurations
Réf.
CONF692001
(Indicative price) €13.53
Details
Details
DN inches NPS 1/8''
DN metric 5/10
Thread standard EN 10226-1 R / ISO 228-1
Stem sealing material FKM O-ring
Type of coating Nickel-plated
Opening device Handle
Application Heating / Sanitary / Drinking water / Air conditioning / Irrigation
Shaft/stem matérial Brass CW614N
Torque (Nm) 106.4
Diameter of passage 6.00
DN 5
Face to Face (mm) 38.0
Fluid Cold water
Body material Brass CW617N
Number of ways 2
Bore Reduced
PS (bar) 16
Connections BSP MF
Seats PTFE
Ball material Chrome-plated brass CW614N
TS max (°C) 90
TS min (°C) -10
Warranty period 2 years
Handle material Nylon
Handle type Black handle

Configurations

Product Reference Price Stock
Mini brass ball valve 692 male/female for compressed air 1/8'' 692001 €13.52
2354 pcs available in stock
Mini brass ball valve 692 male/female for compressed air 1/4'' 692002 €13.70
321 pcs available in stock
